Lineshaft conveyors are a simple and low-cost solution to many product transportation problems.
We manufacture reliable lineshaft modules including straights, bends, merges, and also switches. Precision bearings are used within the conveyor rollers to reduce noise levels.
The Lineshaft conveyor generally is a universal conveyor that is ideal for integration into conveyor systems carrying boxes or totes, and other flat-bottomed unit loads.
Lineshaft conveyors are a great way to safely transport items in a warehouse environment. When an item on the conveyor reaches the desired stopping point, extra friction will cause the o-ring band to slip. As a result, the rollers underneath the package will stop turning. This allows products to accumulate on the conveyor without running off, or causing stoppages in other sections of the conveyor.
For all enquiries please contact our helpful design & sales teams
Phone: 01482 363445
Email: sales@spaceguard.co.uk
Request A Quote
Please fill in the form below, and a specialist will contact you to find out about your exact needs, possibly schedule a site visit and/or provide a comprehensive quote.
If you would like a quote immediately, please provide some details about what you need including dimensions where possible. If you don’t know exactly what you need, just let us know what you’re trying to achieve and we will help you find the most suitable products.
Please contact our sales team to discuss your specific requirements on 01482 363445 or email sales@spaceguard.co.uk
What do you need from your lineshaft conveyor?
Do you need storage, packaging dispensers, IT integration, or accessories?
We will offer advice if you need any help.
Once you know what you want, send it over to us.
Our expert in-house design team will then produce 3D drawings & renders so you can visualise your lineshaft conveyor clearly.
At this point, you can make changes as necessary before finalising the design.
Once you’re happy with it we can discuss your preferred payment method & terms.
Once payment terms have been agreed, our skilled manufacturing team will build your lineshaft conveyor.
You can have them installed or shipped directly to you from our East Yorkshire factory.
Straight sections |
Bends |
90° Transfers & merges |
350mm – 1050mm |
To suit customer application |
50mm diameter |
double grooved |
stainless steel or zinc plated |
Stainless Steel or Powder Coated Mild Steel |
10 – 30 m/min |
Product Blade Stops |
Roller Brakes |
Switches |
Product Blade Stops |
Merges |
Transfers |
Yes Spaceguard offers a full service from design through to installation, including onsite maintenance aftercare.
The lineshaft generally operates best running at speeds between 10 metres per minute, and 30 metres per minute.
There needs to be 3 rollers underneath the box, so 225mm is normally the smallest length box.
