Lineshaft driven roller conveyors and line shaft conveyor systems, built in the UK.
Lineshaft conveyors are a simple and low-cost solution to many product transportation problems. We manufacture reliable lineshaft modules including straights, bends, merges, and also switches. Precision bearings are used within the conveyor rollers to reduce noise levels.
The Lineshaft conveyor generally is a universal conveyor that is ideal for integration into conveyor systems carrying boxes or totes, and other flat bottomed unit loads.
Lineshaft conveyors are a great way to safely transport items in a warehouse environment. When an item on the conveyor reaches the desired stopping point, extra friction will cause the o-ring band to slip. As a result, the rollers underneath the package will stop turning. This allows products to accumulate on the conveyor without running off, or causing stoppages in other sections of the conveyor.
For all enquiries please contact our helpful design & sales teams
Phone: 01482 363445
Email: sales@spaceguard.co.uk
It is a low pressure accumulation or product transport roller conveyor. A shaft beneath the rollers drives this type of conveyor. A friction spool on this shaft for each roller attaches to the rollers by polyurethane o-rings. This transfers the drive from the lower positioned shaft up to the rollers. An electric motor powers the shaft, as the shaft spins, each o-ring drives its corresponding roller.
This type of conveyor has been an industry staple for 50+ years.
As lineshaft driven roller conveyors are a low cost and efficient transportation method, they are widely used across a variety of industries.
These conveyors can handle loads up to 50Kg per metre, for heavier loads try chain driven roller conveyors.
| Module types manufactured: | Straight sections, bends, 90° Transfers & merges |
|---|---|
| Widths: | 350mm - 1050mm |
| Lengths: | To suit customer application |
| Rollers: | 50mm diameter, double grooved, stainless steel or zinc plated |
| Frame: | Stainless Steel or Powder Coated Mild Steel |
| Speeds: | 10 - 30 m/min |
| Accessories: | Product Blade Stops, Roller Brakes & switches |
| Further Options: | Bends, Merges, Transfers |
Every system is designed and manufactured to order in the UK. Tell us what you need and our team will help you spec it and send a fast, free quotation.
Yes Spaceguard offers a full service from design through to installation, including onsite maintenance aftercare.
The lineshaft generally operates best running at speeds between 10 metres per minute, and 30 metres per minute.
There needs to be 3 rollers underneath the box, so 225mm is normally the smallest length box.
Enter your conveyor specification to estimate the nominal and recommended drive power.
Please fill in every field with a valid number.
Figures are indicative and intended as a guide for initial sizing. Friction factor 0.1, gearbox efficiency 75%, safety factor 1.25. Please contact our sales team to confirm the specification for your application.
Lineshaft roller conveyors are a low cost and energy saving conveyor, ideal for transport and accumulation applications.
