Extra Wide Belt Conveyors

Extra Wide Belt Conveyors Manufactured in the UK

Extra wide belt conveyors can be manufactured for situations where wider belts would better suit customer requirements.

We manufacture wider belt conveyors with widths of up to two metres, and lengths to suit your specification.

If you are unsure of what exact specification you require then please contact us. Our team have in-depth experience in a wide range of industries and their specific needs. Through a short phone call or email exchange, we will be able to help you decide on the best industrial conveyor belt to suit your needs.

Please contact our helpful sales team to discuss your requirements.

Phone: 01482 363445
Email: sales@spaceguard.co.uk

Request A Quote

Please fill in the form below and a extra wide belt conveyor specialist will contact you to find out about your exact needs, possibly schedule a site visit and/or provide a comprehensive quote.

If you would like a quote immediately, please provide some details about what you need including dimensions where possible. If you don’t know exactly what you need, just let us know what you’re trying to achieve and we will help you find the most suitable products.

Extra Wide Belt Conveyors

We offer a wide range of competitively priced conveyor products to suit all industrial sectors, environments and applications.

Please contact our helpful sales team with your requirements to receive a free quotation.

Length:	500mm to 10,000mm
Belt Width:	Up to 2000mm
End Roller Diameters:	Dependant on application
Roller materials:	Mild Steel / Stainless Steel
Belt Type:	2ply PVC 3ply PVC Rubber Anti-Cut Belt Oil Resistant Belt
Drive Type:	Geared motor
Drive position:	End drive
Conveyor loading:	Dependant on application
Speeds:	300mm to 30 metres per minute
Conveyor Construction:	Formed steel slider bed
Frame material:	Painted Mild steel or Stainless Steel
Conveyor Finish:	Epoxy powder coated (RAL5010 as standard) or Stainless Steel
Supports:	Welded ‘H’ section
Support Base:	Adjustable feet (+/- 50mm) or Castors
Control Options:	Start/Stop, Variable Speed, Remote Stop
Standard Input Voltage:	1ph 230v 3ph 400v
Optional Extras:	PEC Sensor Side guides Forward / Reverse

Conveyor Options & Accessories

Extra wide conveyor belts are manufactured to the very same high standards as our standard / medium duty conveyors.

We use proven quality components at our factory here in the UK, making Spaceguard your ideal manufacturing partner.

Our wide conveyor range is available with the following accessories.

Fixed or Adjustable Side guides
Quick Release
Swan neck & Nose over
Castors
Electrical controls

We Work With Businesses to Provide Bespoke Extra Wide Belt Conveyors

So far we've helped over 1673 businesses get the equipment they need!

Follow These Simple Steps to Get Your Bespoke Extra Wide Belt Conveyors

Consider your requirements

What do you need from your extra wide belt conveyors?

Do you need storage, packaging dispensers, IT integration, or accessories?

We will offer advice if you need any help.

Tell us what you need

Once you know what you want, send it over to us.

Our expert in-house design team will then produce 3D drawings & renders so you can visualise your extra wide belt conveyors clearly.

We email your quotes to you

At this point, you can make changes as necessary before finalising the design.

Once you’re happy with it we can discuss your preferred payment method & terms.

We make your extra wide belt conveyors

Once payment terms have been agreed, our skilled manufacturing team will build your extra wide belt conveyors.

You can have them installed or shipped directly to you from our East Yorkshire factory.
